A lightweight, compact body easy to use.
- Print character height up to 25 mm
- The graphic LCD screen displays large, clear characters.
- The operation buttons are large and color-coded.
- All-in-one design, accessories can be neatly stored inside the body
- Compact design makes it easy to retrofit to existing lines
The HQC Benefits
Lightweight and Compact
Contemporary design, accommodate all accessories neatly in the body.
Fully features and budget-friendly
Two controllers can be connected with a communication cable, allowing data to be copied between devices.
Lightweight Compact Easy to use
User friendly display screen and easy operation. Main body weight is just 3 Kgs
Samples
Sample-2
Sample-1
Product Specification
| Format | HQC |
| Printing Method | Piezo type |
| Nozzle Array | 32 nozzles 2 holes/nozzle |
| Ink ejection direction | Horizontal |
| Maximum Print Speed | 200m/min |
| Character height | 2~25mm |
| Number of Heads | 1 |
| Workpiece detection | Photoelectric sensor (fixed head type/external type) |
| Number of printing columns | 1st row (32x32 dots), 2nd row (16x16 dots) |
| Number of registered messages | 30 Messages |
| Registered modules per message | 48 characters |
| Character type | Alphanumeric characters, symbols, katakana, kanji (48 characters), user-registered characters (180 characters selected by the customer are registered before shipment) |
| Character font | Gothic font (16-dot font can be selected between bold and thin) |
| Date and time printing | Year (Western/Japanese calendar), month, date, hour (12/24H), minute, free format, offset value can be set, calendar character allocation function |
| Numbering | Up to 8 digits, up/down, repeat count, increment value setting |
| Barcode | No |
| Graphic | No |
| External Interface | I/O: 3 outputs (Ready, Ink LOW, Warning) |
| RS232C: Used only for data backup, restoration, and software upgrades | |
| Operating environment | 5 to 35°C, 10 to 80% RH (no condensation) |
| Ground | D type grounding |
| Power supply | AC230V + 10PHZ / 40W |
Product Diagram
